IMP65 Aerial Work Platform

Mantall® IMP65 aerial work platform is a vertical mast lift with a maximum working height of 6.5 meters. It features an extended platform, zero inside turning radius, 30% gradeability, spring hydraulically released braking system and 25cm non-marking solid rubber tires. Its compact structure and small size make it easy to pass through narrow passages and doorways. IMP65 aerial work platform is widely used in indoor work fields such as warehousing, inventory management, transportation, and inventory picking, which can significantly improve work efficiency and productivity.

Standard Features

  • Emergency lower down
  • The Platform entrance height for a minimum of 0.38 meters
  • Proportional Raising and Driving Control
  • Diagnosis system
  • AC wiring to platform
  • Lowering and tilt alarm
  • Turn Inter-radius is 0
  • Double wheel brake
  • Hydraulic brake release
  • Pothole guards
  • The rear shield mounted with hinge, conveniently to close to all major electric and hydraulic components.
  • Transportation fixing hole
  • Wide type forklift handling notch
  • Non-mark solid tire

IMP65 Aerial Work Platform Specifications

Specification Value
Max Working Height 6.5 m
Lifting Capacity 230 kg
Overall Width 0.8 m
Overall Length 1.4 m
Weight 993 kg


  • Extendable platform
  • Fiber glass platform
  • Goods collection platform
  • Motion alarm
  • Tool box
  • Platform positioning laser light
  • Fluorescent tubes box
  • Working flashing beacon
  • Top limit protection auto-stop device
  • Equipment protection cover
